Based on the new-generation Impinj E710 RFID chip, this compact UHF RFID reader module delivers reliable tag reading performance for embedded and mobile applications.
Features
- Based on the new generation Impinj E710 chip.
- Supports EPCglobal UHF Class 1 Gen 2 & Gen 2X.
- 33dBm RF output power.
- High performance collision avoidance recognition algorithm.
- Low power consumption, small size, suitable for all-in-one equipment, personnel management or handheld devices, clothing asset inventory.
Specifications
| Physical | |
| Size | 55.8mm x 35.5mm x 6mm |
| Weight | 21g |
| Connector material | Brass gold plated |
| PCB | FR4 gold plated |
| Shield Material | Aluminum Alloy |
| RFID | |
| Chip | Impinj E710 |
| Air Protocol | EPC global UHF Class 1 Gen 2 (ISO 18000-6C) & Gen 2X |
| Frequency | NA: 902 ~ 928MHz |
| EU: 865 ~ 868MHz | |
| CN: 920 ~ 925MHz | |
| OPEN:860 ~ 960MHz | |
| Sensitivity | -87dBm@10%BER |
| Antenna | One 50Ω MMCX port |
| RF Power | 5dBm ~ 30 or 33dBm (±1dB) |
| Working Mode | Fixed / Hop frequency |
| RSSI; Temp. detect | Support |
| RFID | |
| Inventory peak speed | >1000 tags/s |
| read range | >5m（2.5dBi antenna） |
| tag cache | 1000pcs, @96 bit EPC |
| Communication Interface | |
| Hardware interface | UART serial port (power, TTL, GPIO)9600~921600bps,@115200bps |
| GPIO | 2 GPI, 2 GPO （3.3V TTL） |
| Communication | 12pin connector Uart 3.3V (TTL) |
| Power supply | |
| Voltage | DC 3.6 ~ 5.25V |
| Consumption | 6.75W（peak）, 1.35A@5V0.75W（standby）, 0.15A@5V0.1W（Low power mode standby）, 0.02A@5V |
| Environment features | |
| Work Temp. | -25°C ~ +65°C |
| Storage Temp. | -40°C ~ +85°C |
| Humidity | 5 ~ 95%, Non-condensing (+25°C) |
| Electrostatic Protection | Contact discharge: 8KV (antenna port)Contact discharge: 2KV (IO port) |
| Heat dissipation | External heat sink air cooling |
| API | |
| API support | C, C#/.NET, Java |
