URE4 features the Impinj E710 chipset, with a read range of up to 25 m and reading speeds of up to 1,000 tags/s. Its rugged aluminum housing is designed for industrial environments.
Features
- Impinj E710 chip for fast and reliable RFID performance.
- EPC C1 Gen2 / ISO18000-6C compliant.
- Up to 25 m read range with adjustable RF power (5–33 dBm).
- High reading speed of up to 1,000 tags per second.
- 4 antenna ports for flexible coverage and deployment.
- Multiple interfaces: RJ45, RS232, RS485, USB, and Wiegand.
- 4 inputs and 4 relay outputs for easy system integration.
- Supports global UHF bands: 865–868 MHz and 902–928 MHz.
- CNC-machined billet aluminum housing for durability and efficient heat dissipation.
- Suitable for asset tracking, logistics, warehousing, and industrial automation.
Specifications
| SYSTEM | |
| Firmware Upgrade | Demo software |
| API Support | C#, Android, Java |
| PHYSICAL | |
| Dimensions | 244mm ×117mm × 31mm |
| Weight | 0.9 Kg |
| Housing Material | CNC-machined aluminum |
| RFID | |
| Air Protocols | ISO/IEC18000-6B, 6C / EPC C1Gen2 |
| Frequency | USA: 902 MHz-928MHz (FCC part 15) |
| EU: 865-868MHz (ETSI EN 302208) | |
| Chipset | Impinj E710 |
| Read range | 0-25 m |
| Read Speed | Max 1000 time/sec |
| Output Power: | 5dBm-33dBm (±1dBm) adjustable |
| Channel bandwidth: | ＜200KHz |
| Anti-collision | Support multi-tag / intensive inventory |
| Work Mode: | Fixed/hop frequency optional |
| CONNECTIVITY | |
| Communications | RJ45, RS232, RS485, USB, Wiegand |
| General Purpose I/O | 4 inputs(DC 0~24V), 4 outputs(DC_MAX:30V,2A; AC_MAX:125V,0.3A), optically isolated (Terminal Block) |
| Power supply | DC 12V/3A |
| POE | IEEE 802.3 af/at (Optional) |
| Wireless | WiFi, Bluetooth, 4G (Optional, select one) |
| Antenna Ports | 4 Reverse Polarity TNC ports |
| ENVIRONMENTAL | |
| Operating Temp. | -30 – +65°C |
| Storage Temp. | -40 – +85°C |
| Humidity | 5-95% non-condensing (+25℃) |
| Sealing | IP55 |
