The SLD1030 is a development board designed to facilitate the testing of RFID modules and the assembly of complete machines. It can directly connect to various modules, including SIM7100, SIM5100, and SIM3100. It can also be paired with a housing to form a fixed reader, suitable for various industrial application scenarios.
Features
- Multiple communication interfaces, including Ethernet, RS232, RS485, USB, and Wiegand.
- 4 digital inputs and 4 high-current outputs, supporting up to 250 mA per output.
- Wi-Fi and Bluetooth connectivity available as optional features.
- Supports Modbus, HID, HTTP/HTTPS, MQTT, TCP, and Wiegand protocols.
Specifications
| SYSTEM | ||
| Processor | ARM Cortex-M4 (200 MHz) | |
| Flash+SRAM | 512 KB+ 192KB | |
| PHYSICAL | ||
| Dimensions | 70mm * 55.9mm * 12.2mm | |
| Weight | 0.15 Kg | |
| ESD protection | ±8 kV air discharge, ±6 kV contact discharge | |
| Surge protection | ±4 kV | |
| Indicator lights | Power indicator (green); status indicator (red) | |
| Power supply | 9–24V DC (Adapter: 12V/2A) | |
| POE | IEEE 802.3 af/at (Optional) | |
| Power Consumption | Equipped with SIM7100, standby is 1.76W, operation is 6.75W; The Single board is 0.36W during operation | |
| CONNECTIVITY | ||
| Interfaces | Ethernet (10M/100M adaptive)RS232 (9,600–230,400 bps)USB (9,600–921,600 bps)RS485 (19,200-230,400bps)Wiegand | |
| GPIO | 4 inputs; 4 strong-driver outputs (each pull-up current up to 250 mA) | |
| Wireless | WiFi, Bluetooth (Optional) | |
| Protocols | Modbus, HID, HTTP, HTTPS, MQTT, TCP, WG34/26/66 | |
| ENVIRONMENTAL | ||
| Operating temperature | −25°C to +65°C | |
| Storage temperature | −40°C to +85°C | |
| Humidity | 5–95% non-condensing | |
| Sealing | IP55 | |
